Oil Drilling Rig Mats

The oil drilling rig mats are a portable structural support platform commonly used for large equipment such as oil drilling rigs. Typically constructed of wood, steel, or rubber, it allows workers to perform operations in a variety of conditions while protecting the environment. For example, using a rig pad on a land-based oil rig might allow users to operate throughout oil extraction periods when the ground is too unstable to support the necessary equipment and personnel during wet or rainy seasons.

Oil Drilling Rig Mats Technical Specifications

Model	Length（mm）	Width（mm）	Height（mm）	Weight（kg）
HGM3220	3000	2000	200	1200
HGM4220	4000	2000	200	1600
HGM5220	5000	2000	200	2000
HGM3218	3000	2000	180	1080
HGM4218	4000	2000	180	1440
HGM5218	5000	2000	180	1800
HGM3218	3000	2000	160	960
HGM4218	4000	2000	160	1280
HGM5218	5000	2000	160	1600

Application of drilling rig mats

1. Oil drilling rig mats are commonly used in oil drilling, serving as pads for drilling rigs. They can also be used in other industrial applications.

2. Drilling rig mats can also provide a safe, stable working surface for mining operations in wet or icy areas.

3. Steel-timber foundations can also provide a solid foundation for contractors or other workers to store equipment or materials.

4. In remote areas, rig mats can also serve as temporary roads, paving the way for vehicles to traverse dangerous terrain, and even as helicopter landing pads.
