Oil Rig Mats

Oil rig mats are portable structural support platforms commonly used on large equipment such as oil drilling rigs. Typically constructed of wood, steel, or rubber, they enable workers to perform operations in a variety of conditions while protecting the environment. For example, a drilling mat used on a land-based oil drilling rig might allow users to operate throughout the entire oil extraction process, even when the ground is too wet or unstable to support the necessary equipment and personnel during rainy seasons.

Oil rig mats replace traditional concrete foundations, significantly reducing drilling costs and improving economic efficiency, conserving land and enhancing site management.

Advantages of Rig Mats

This product offers high strength, strong load-bearing capacity, excellent interchangeability, convenient transportation, low cost, quick and easy installation, strong shock absorption, resistance to cracking, water resistance, corrosion resistance, deformation resistance, long service life, and easy recycling and storage.

Oil Rig Mats Technical Specifications

Model	Length（mm）	Width（mm）	Height（mm）	Weight（kg）
HGM3220	3000	2000	200	1200
HGM4220	4000	2000	200	1600
HGM5220	5000	2000	200	2000
HGM3218	3000	2000	180	1080
HGM4218	4000	2000	180	1440
HGM5218	5000	2000	180	1800
HGM3218	3000	2000	160	960
HGM4218	4000	2000	160	1280
HGM5218	5000	2000	160	1600

Applications of Drilling Mats

1. Rig mats are a hybrid type of foundation that combine the strength and durability of steel with the versatility and cost-effectiveness of wood. These foundations, often in the form of drilling mats, are essential in industrial sectors, particularly in environments with unstable or wet ground.

2. Steel-timber foundations can also provide a safe and stable working surface for mining operations in wetlands or icy areas.

3. Contractors or other workers can also use rig mats as a solid base to store equipment or materials.

4. In remote areas, steel-timber foundations can also serve as temporary roads, paving the way for vehicles to traverse dangerous terrain, and even as helicopter landing pads.
